Description

imageCLASS LBP228x

Intuitive navigation, Advanced features

With the Application Library to customise workflows, Department ID to monitor printer utilisation, and the 5-inch colour touchscreen LCD panel for easy navigation of settings, LBP228x is the ideal solution for office document needs.

• Print Speed (A4): Up to 38ppm
• First Print Out Time (A4): Approx. 5.5 sec
• Print resolution: Up to 1200 x 1200dpi (equivalent)
• Mobile Printing
• Gigabit Ethernet, Wireless, Direct Connection
• Recommended Monthly Print Volume 750 – 4,000 pages





Print

• Printing Method	Monochrome Laser Beam Printing
  	Print Speed
  A4	38 ppm
  Letter	40 ppm
  2-sided	31 ppm (A4)/ 33 ppm (Letter)
  Print Resolution	600 x 600 dpi
  Print Quality with Image Refinement Technology	1,200 (eq.) x 1,200dpi (eq.)
  Warm up Time (From Power On)	14 sec or less
  	First Print Out Time (FPOT)
  A4	Approx. 5.5 sec
  Letter	Approx 5.4 sec
  Recovery Time (From Sleep Mode)	4.0 sec or less
  Print Language	UFR II, PCL 6 , Adobe® PostScript® 3™
  Auto Duplex Print	Standard
  Available Paper Size for Auto Duplex Print	A4, Letter, Legal, Foolscap, Indian Legal
  Print Margins	5mm – top, bottom, left and right (Envelope: 10mm)
  Print Features	Poster, Booklet, Watermark, Page Composer, Toner Saver
  USB Direct Print	Supported
  Supported File Format for USB Direct Print	Supported File Format: JPEG, TIFF, PDF

Paper Handling

• 	Paper Input (based on 80g/m²)
  Standard Cassette	250 sheets
  Multi-Purpose Tray	100 sheets
  Optional Paper Feeder	550 sheets
  Maximum Paper Input Capacity	900 sheets
  Paper Output	150 sheets
  	Paper Sizes
  Cassette / Optional Paper Feeder	A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian LegalCustom (Min. 105.0 x 148.0mm to Max. 216.0 x 355.6mm)
  Multi-Purpose Tray	A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Index Card Envelope: COM10, Monarch, C5, DLCustom (Min. 76.2 x 127.0mm to Max. 216.0 x 355.6mm)
  Paper Types	Plain, Heavy, Recycled, Colour, Label, Postcard, Envelope
  	Paper Weight
  Cassette / Optional Paper Feeder	60 to 120g/m²
  Multi-Purpose Tray	60 to 163g/m²

Connectivity & Software

• 	Standard Interfaces
  Wired	USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T
  Wireless	Wi-Fi 802.11b/g/n(Infrastructure mode, WPS easy Setup, Direct Connection)
  	Network Protocol
  Print	LPD, RAW, WSD-Print (IPv4,IPv6)
  TCP/IP Application Services	Bonjour(mDNS), HTTP, HTTPS, POP before SMTP (IPv4,IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6)
  Management	SNMPv1, SNMPv3 (IPv4,IPv6)
  	Network Security
  Wired	IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1x, IPSEC
  Wireless	WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES)
  Other Features	Department ID, Secure Print
  Mobile Solution	Canon PRINT Business, Canon Print Service, Google Cloud Print™, Apple® AirPrint®, Mopria® Print Service
  Compatible Operating Systems	Windows® 10, Windows® 8.1, Windows® 7, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008,Mac® OS X 10.9.5 & up*1, Linux*1
  Software Included	Printer driver, Toner Status

General

• Device Memory	1 GB
  LCD Display	WVGA 5.0″ Colour Touchscreen LCD
  Dimensions (W x D x H)	438 x 373 x 312mm
  Weight	Approx. 9.2 kg
  	Power Consumption
  Maximum	1,330 W or less
  During Operation (Average)	Approx. 480W
  During Standby (Average)	Approx. 9.0W
  During Sleep (Average)	Approx. 0.9W (USB/ LAN / Wi-Fi)
  	Operating Environment
  Temperature	10 – 30°C
  Humidity	20% – 80% RH (no condensation)
  Power Requirements	AC 220 – 240V (+/-10%), 50/60 Hz (+/-2Hz)
  	Noise Levels
  During Operation	Sound Pressure Level: 54 dBSound Power Level: 6.8 B
  During Standby	Sound Pressure Level: inaudibleSound Power Level: inaudible
  	Toner Cartridge
  Standard	Cartridge 057: 3,100 pages (bundled: 3,100 pages)
  High	Cartridge 057H: 10,000 pages
  Monthly Duty Cycle	80,000 pages

Optional Accessories

• Paper Feeder	Cassette Feeding Unit-AH1 (550 sheets)
  Barcode Printing	Barcode Printing Kit-E1
  Attachment kit for NT-Ware Mi-Card	Mi-Card Attachment Kit-B1

  1. The latest drivers for Mac OS and Linux can be downloaded from the https://asia.canon website when available.
  2. Tested in accordance to ISO 7779 and declared per ISO 9296.
  3. Toner cartridge yield is in accordance with ISO/IEC 19752.
  4. Monthly Duty Cycle value provides a means of comparison for product robustness in relation to other Canon laser printer devices, and does not refer to actual maximum image output per month.
