Description

PIXMA GM2070

Refillable Ink Tank Wireless Printer for High Volume Monochrome Printing

Design for high volume monochrome printing at low running cost. This printer also has the option for colour document printing.

• Print
• ISO standard print speed (A4): up to 13.0 ipm black
• Wireless, Wired LAN, Wireless/Wired LAN Pictbridge, Direct Wireless
• Recommended monthly print volume: 150 to 1,500 pages

Print

Print Head / Ink
Type	Permanent (Replaceable)
Number of Nozzles	Black: 640 nozzles (Optional Colour: 1152 nozzles)
Ink Bottles / Cartridges	GI-70 (Pigment Black) Optional: CL-741, CL741XL
Maximum Printing Resolution	600 (horizontal)*1 x 1200 (vertical) dpi
Print Speed*2 Based on ISO/IEC 24734 Click here for Summary Report Click here for Document Print and Copy Speed Measurement Conditions
Document (ESAT/Simplex)	Approx. 13.0 ipm (black) / 6.8 ipm (colour)
Document (ESAT/Duplex)	Approx. 4.8 ipm (black) / 2.8 ipm (colour)
Document (FPOT Ready / Simplex)	Approx. 9 sec (black) / 14 sec (colour)
Printable Width	Up to 203.2mm (8″)
Printable Area
Borderless Printing*3	–
Bordered Printing	#10 Envelope/DL Envelope: Top 8 mm / Bottom 12.7 mm / Right 5.6 mm / Left 5.6 mmLTR / LGL: Top 3 mm / Bottom 5 mm / Right 6.3 mm / Left 6.4 mmOthers: Top 3 mm / Bottom 5 mm / Right 3.4 mm / Left 3.4 mm
Bordered Auto 2-Sided Printing	Top / Bottom margin: 5 mm, Left / Right margin: 3.4 mm (LTR: Left: 6.4 mm, Right: 6.3 mm)
Support Media
Rear Tray	Plain Paper (64 – 105 g/m²) High Resolution Paper (HR-101N) Envelope
Cassette	Plain Paper (64 – 105 g/m²)
Paper Size
Rear Tray	A4, A5, B5, LTR, LGL, Envelopes (DL, COM10), Card Size (91 x 55 mm) [Custom size] width 55 – 215.9 mm, length 89 – 676 mm
Cassette	A4, A5, B5, LTR [Custom size] width 148.0 – 215.9 mm, length 210 – 297 mm
Paper Handling (Maximum Number)
Rear Tray	Plain Paper (A4, 64 g/m²) = 100 High Resolution Paper (HR-101N) = 80
Cassette	Plain Paper (A4, 64 – 105 g/m²) = 250
Support Media for Auto 2-sided printing
Type	Plain Paper
Size	A4, A5, B5, LTR
Paper Weight
Rear Tray	Plain Paper: 64 – 105 g/m²
Cassette	Plain Paper: 64 – 105 g/m²
Ink End Sensor	Electrode type and dot count type combined Optional Colour Cartridge; Dot count
Print Head Alignment	Auto/Manual

Network

Protocol	TCP/IP, SNMP
Wired LAN
Network Type	IEEE802.3u (100BASE-TX) / IEEE802.3 (10BASE-T)
Data Rate	10M/100Mbps (Auto switchable)
Wireless
Network Type	IEEE802.11n/g/b
Frequency Band	2.4 GHz
Channel*4	1 – 13
Range	Indoor 50 m (Depends on the transmission speed and conditions)
Security	WEP64/128 bit WPA-PSK (TKIP/AES) WPA2-PSK (TKIP/AES)
Direct Connection (Wireless LAN)	Available

Printing Solutions

Canon Print Service for Android	Available
PIXMA Cloud Link (from smartphone/tablet)	Available
Canon PRINT Inkjet/SELPHY (for iOS/for Android)	Available

System Requirements*5

Windows 10 / 8.1 / 7 SP1 (Operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)

General Specifications

Language	32 Selectable Languages: Japanese / English / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovakian / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Thai / Croatian / Vietnamese
Interface	Hi-Speed USB 2.0
PictBridge (Wireless / Wired LAN)	Available
Operating Environment*6
Temperature	5 – 35°C
Humidity	10 – 90% RH (no dew condensation)
Recommended Environment*7
Temperature	15 – 30°C
Humidity	10 – 80% RH (no dew condensation)
Storage Environment
Temperature	0 – 40°C
Humidity	5 – 95% RH (no dew condensation)
Quiet Mode	Available
Acoustic Noise (PC Print)
Plain Paper (A4, B/W)*8	Approx. 52.0 dB(A)
Power	AC 100-240 V, 50/60 Hz
Power Consumption
OFF	Approx. 0.3 W
Standby (scanning lamp is off) USB connection to PC	Approx. 0.8 W
Standby (all ports connected, scanning lamp is off) [EU only – for ErP Lot 26 regulation]	Approx. 1.6 W
Time to enter Standby mode [EU only – for ErP Lot 26 regulation]	Approx. 1 min 29 sec
Printing*9 USB connection to PC	Approx. 13 W
Environment
Regulation	RoHS (EU, China), WEEE (EU)
Duty Cycle	Up to 15,000 pages/month
Dimension (WxDxH)
Factory Configuration
