Canon PIXMA GM4070 AIO All-In-One Refillable Ink Tank Direct Wireless Network Monochrome Printer For High Volume Printing

Description

PIXMA GM4070

Refillable Ink Tank Wireless Printer with ADF for High Volume Monochrome Printing

Designed for high volume monochrome printing at low running cost. This printer also has the option for colour document printing.

• Print, Scan, Copy
• ISO standard print speed (A4): up to 13.0ipm black
• Wireless, Wired LAN, Wireless/Wired LAN Pictbridge, Direct Wireless
• Recommended monthly print volume: 150 to 1,500 pages

Print

	Print Head / Ink
Type	Permanent (Replaceable)
Number of Nozzles	Black: 640 nozzles (Optional Colour: 1152 nozzles)
Ink Cartridges	GI-70 (Pigment Black)Optional: CL-741, CL741XL
Maximum Printing Resolution	600 (horizontal)*1 x 1200 (vertical) dpi
	Print Speed Based on ISO/IEC 24734Click here for summary reportClick here for Document Print and Copy Speed Measurement Conditions
Document (ESAT/Simplex)	Approx. 13.0 ipm (black) / 8.8 ipm (colour)
Photo (4 x 6″) (PP-201/Borderless)	–
Printable Width	Up to 203.2 mm (8″)
	Printable Area
Bordered Printing	#10 Envelope/DL Envelope:Top 8 mm / Bottom 12.7 mm / Right 5.6 mm / Left 5.6 mmLTR / LGL:Top 3 mm / Bottom 5 mm / Right 6.3 mm / Left 6.4 mmOthers:Top 3 mm / Bottom 5 mm / Right 3.4 mm / Left 3.4 mm
Bordered Auto 2-Sided Printing	Top / Bottom margin: 5 mmLeft / Right margin: 3.4 mm (LTR: Left: 6.4 mm, Right: 6.3 mm)
	Support Media
Rear Tray	Plain Paper (64 – 105 g/m²)High Resolution Paper (HR-101N)Envelope
Cassette	Plain Paper (64 – 105 g/m²)
	Paper Size
Rear Tray	A4, A5, B5, LTR, LGL, Envelopes (DL, COM10), Card Size (91 x 55 mm)[Custom size]width 55 – 215.9 mm, length 89 – 676 mm
Cassette	A4, A5, B5, LTR[Custom size]width 148.0 – 215.9 mm, length 210 – 297 mm
	Paper Handling (Maximum Number)
Rear Tray	Plain Paper (A4, 64 g/m²) = 100High Resolution Paper (HR-101N) = 80
Cassette	Plain Paper (A4, 64 g/m²) = 250
	Support Media for Auto 2-sided printing
Type	Plain Paper
Size	A4, A5, B5, LTR
	Paper Weight
Rear Tray	Plain Paper: 64 – 105 g/m²
Cassette	Plain Paper: 64 – 105 g/m²
Ink End Sensor	Electrode type and dot count type combinedOptional Colour Cartridge; Dot count
Print Head Alignment	Auto/Manual

Scan*3

Scanner Type	Flatbed
Scanner Method	CIS (Contact Image Sensor)
Optical Resolution Optical resolution scan is available, only when you use TWAIN Driver.	1200 x 2400 dpi
	Scanning Bit Depth (Input/Output)
Grayscale	16 bit/8 bit
Colour	RGB each 16 bit/8 bit
	Line Scanning Speed
Grayscale	1.5 ms/line (300 dpi)
Colour	3.5 ms/line (300 dpi)
	Maximum Document Size
Flatbed	A4/LTR (216 x 297 mm)
ADF	A4/LTR/LGL

Copy

Maximum Document Size	A4/LTR
	Compatible Media
Size	A4/A5/B5/LTR/LGL/Card Size (91 x 55 mm)
Type	Plain Paper
Image Quality	3 positions (Economy, Standard, High)
Density Adjustment	9 positions, Auto intensity (AE copy)
	Copy Speed Based on ISO/IEC 24734Click here for summary reportClick here for Document Print and Copy SpeedMeasurement Conditions
Document (B&W) (sFCOT/Simplex) / (sESAT/Simplex)	Approx. 12 sec / approx. 10.7 ipm
Document (ADF): Black ESAT/Simplex	Approx. 11.5 ipm

Network

Protocol	SNMP, HTTP, TCP/IP (IPv4/IPv6)
	Wired LAN
Network Type	IEEE802.3u (100BASE-TX) IEEE802.3 (10BASE-T)
Data Rate	10M/100Mbps (Auto switchable)
	Wireless LAN
Network Type	IEEE802.11n/g/b
Frequency Band	2.4 GHz
Channel*7	1 – 13
Range	Indoor 50 m (depends on the transmission speed and conditions)
Security	WEP64/128 bitWPA-PSK (TKIP/AES)WPA2-PSK (TKIP/AES)
Direct Connection (Wireless LAN)	Available

Printing Solutions

Canon Print Service(for Android)	Available
PIXMA Cloud Link(from smartphone/tablet)	Available
Canon PRINT Inkjet/SELPHY(for iOS/for Android)	Available

System Requirements*8

Windows 10 / 8.1 / 7 SP1(operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)Mac: N/A

General Specifications

	Operation Panel
Display	2-Line LCD
Language	32 Selectable Languages: Japanese / English / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovakian / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Thai / Croatian / Vietnamese
	ADF
